Specifications
Equipped With
Maximum Saw Blade Diameter mm (inch) 450 (17.72)
Rectangular Material 90 degrees mm (inch) 240 x 70 (9.45 x 2.76)
Rectangular Material 45 degrees mm (inch) 170 x 70 (6.69 x 2.76)
Rectangular Material 30 degrees mm (inch) 120 x 70 (4.72 x 2.76)
Square Material 90 degrees mm (inch) 140 (5.51)
Square Material 45 degrees mm (inch) 125 (4.92)
Square Material 30 degrees mm (inch) 100 (3.94)
Round Material 90 degrees mm (inch) 150 (5.91)
Round Material 45 degrees mm (inch) 145 (5.71)
Round Material 30 degrees mm (inch) 120 (4.72)
Drive Performance kW (HP) 7.1 (9.65)
Standard Speed min -1/RPM 6-80
Feed Rate - infinitely variable mm/sec (inch/sec) 0-14 (0-0.55)
Rapid Return of Saw Blade mm/sec (inch/sec) 75 (2.95)
Turntable Swiveling to Both Sides (degree) 30 - 90 - 30
Single Stroke mm (inch) 1,490 (58.66)
Multiple Stroke mm (inch) 9,999.9 (393.70)
Material Feed Rate mm/sec (inch/sec) 500 (19.69)
Reversing Speed mm/sec (inch/sec) 500 (19.69)
Weight approx kg. (approx. lb) 2,600 (5,730)
Dimensions L x W x H mm (inch) 4,200 x 1,345 x 2,050 (165.35 x 52.95 x 80.71)
